U306 IEM Receiver Only 655 MHz – 679 MHz
$359.00 Inc GST
U306 IEM Receiver Only 655 MHz – 679 MHz
- Description
- Reviews (0)
Description
Description
Bodypack Receiver Only
The new LD Systems U 300 IEM In-Ear Monitoring-System with 12 UHF channels offers outstanding sound quality and a large dynamic range in the 655 MHz – 679 MHz
The system toggles between mono and stereo mode for perfect monitoring for live musicians, actors or speakers. A built-in limiter ensures even, distortion-free sound reproduction with a frequency response of 50 Hz – 16 kHz and stands out because of its high signal-to-noise ratio and low total harmonic distortion. The U 300 IEM permits simultaneous operation of up to 6 systems.
Both transmitter and receiver feature multifunctional displays that show all important system information. With high quality batteries, it is possible to attain running times of 10 hours and more.
General
| Product type | In-ear Monitoring Accessories |
| Type | Receivers |
| Transmission frequency range | 655 – 679 MHz |
| Channels | 12 |
| Transmission method | FM, mono/stereo |
| Frequency response | 50 – 16.000 Hz |
| Total Harmonic Distortion (THD) | 0.25 % |
| Audio output | 3.5 mm TRS |
| Minimum connected impedance | 16 Ohm(s) |
| Max. audio output level | 100 (@ 16 Ohms load capacity) mW, 73 (@ 33 Ohms load capacity) mW |
| Antenna connector | Fixed to housing |
| Controls | Channel down, Channel up, on/off switch, volume control |
| Indicators | LC display, RF (LED) |
| Operating voltage | 2 x 1.5 V AA |
| Operating time | < 10 hours |
| Width | 64 mm |
| Height | 103 mm |
| Depth | 24 mm |
| Weight | 0,085 kg |
| Features | battery status LED, incl. batteries |
