dB Technologies LVX P5 Passive Speaker
$399.00 Inc GST
dB Technologies LVX P5 Passive Speaker
- Description
- Reviews (0)
Description
Description
FEATURES
- Full-range passive speaker
- 8 Ohm or 16 Ohm version available
- Max SPL 115dB
- Wooden lightweight enclosure
- Clean design
- Available in black or white
- Bracket included for wall or ceiling installation
LVX P5 is a passive speaker equipped with a full-range single transducer (5” LF and 1” HF).
The most efficient acoustic design, allowing an extended coverage pattern (135°x135°) and a vigorous SPL up to 115 dB, makes this mini full range system the perfect solution to render speech or background music in small venues.
The solid plywood enclosure features a clean, install-friendly design with rigging points on top and side to ease installation on ceiling or wall via the included bracket. LVX P are equipped with Phoenix connectors.
8 or 16 Ohm versions are available for use with dBTechnologies ATI amplifiers.
The cabinet comes in black or white, just like all other cabinets in LVX series.
Technical Data
Speaker Type
Full-range wooden passive loudspeaker
Acoustical data
Impedance
8 Ohms or 16 Ohms
Frequency Response [-10 dB]
100 Hz -20 kHz
Max SPL
115 dB
Directivity
135×135°
LF
5″, 1″ v.c.
Peak Power Handling
120 W
Input
Connector Type
2-pole Phoenix connector type
Mechanics
Housing
Plywood
Accessories
Wall/ceiling mounting bracket (included)
Width
165 mm (6.49 in)
Height
198 mm (7.79 in)
Depth
175 mm (6.88 in)
Weight
2.2 kg (4.8 lbs)
